SmartSolar MPPT 150/60-Tr Charge Controller | Victron SCC115060210
Special Price
$539.75
MSRP:
$635.00
SKU
Brand: Victron EnergyQty In Stock: 0
VICTRON-SCC115060210
SmartSolar MPPT 150/60-Tr Charge Controller
| Warehouse | Available |
- SmartSolar MPPT 150/60-Tr Charge Controller
- Bluetooth Smart Built-in for wireless setup, monitoring, and updates
- VE.Direct gives a wired connection to a Color Control Panel, PC, or other devices
- Load Output Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a preset voltage
- Battery Voltage 12/24/48 VDC Auto Select
- Rated Charge Current 60A
- Nominal PV Power at 12VDC 860W
- Nominal PV Power at 24VDC 1720W
- Nominal PV Power at 36VDC 2580W
- Nominal PV Power at 48VDC 3440W
- Max PV Short Circuit Current 50A
- Data Communication Port VE.Direct
- Maximum PV Open Circuit Voltage 150VDC
- Peak Efficiency 98%
- Self Consumption 12v less than 35mA 48V 20mA
- Charge Voltage Absorption 14.4VDC / 28.8 / 43.2 / 57.6 VDC (adjustable)
- Charge Voltage Float 13.8VDC / 27.6 / 41.4 / 55.2 VDC (adjustable)
- Charge Algorithim Multi-stage adaptive
- Protection Battery reverse polarity (fuse) / PV Reverse Polarity / Output short circuit / Over temperature
- Operating Temperature -30 to +60 deg C
- Humidity 95% non-condensing
- PV Terminals 3
